For drug products intended for storage at sub-zero temperatures, NEWTRONIC Deep Freezers provide a very optimal solution by offering a wide temperature range from -25°C to 0°C.
The switchover to Standby system is automatic & immediate upon detection of a fault in Primary.
If desired, the switchovers can also be scheduled or manual ones.
They also offer automatic defrost by utilizing a heater to defrost the condenser coils, which cycles on and off, preventing any ice build-up. Their robust compressors and CFC-free insulation help ensure temperature uniformity and sample protection.
Ss304 Inner body | Pre Coated Galvanised Iron Outer body |
High density CFC free PUF insulation | Multi layer transparent door with lock & handle |
Magnetic gasket is provided for airtight sealing | Electronic controller with digital display |
Castor wheels are provided for easy movement with an option for having locks | Bright LED interior lighting |
Temperature deviation alarm and door ajar alarm | CFC free cooling system |
The compressor is hermetically sealed for better efficiency | It has low noise and has low power consumption |
230 Volts 50 Hz main supply. Also available with 60 Hz cycle | Anti-frost safety device |
Data Logger to automatically record parameters | Adjustable Trays |
Circular chart recorder to archive data points over a time interval | Bright LED Lights |
Digital Controller with Audio Visual Alarm | Low Power Consumption |
Low Noise Cooling Design |
Model | Capacity – CuFt. | Capacity – Litres | Internal Size – (HxWxD) mm | External Size – (HxWxD) mm | Trays Qty. | Tray Size – (WxD) mm | Approx. Weight – Eqip. Kg | Approx. Weight – Ship. Kg |
---|---|---|---|---|---|---|---|---|
NLDF7MI | 7 | 200 | 510 x 560 x 700 | 1500 x 720 x 880 | 2 | 540 x 605 | 175 | 250 |
NLDF11MI | 11 | 300 | 910 x 560 x 590 | 1955 x 720 x 770 | 3 | 540 x 495 | 225 | 300 |
NLDF14MI | 14 | 400 | 910 x 560 x 785 | 1955 x 720 x 965 | 3 | 540 x 690 | 275 | 350 |
NLDF25MI | 25 | 700 | 1200 x 800 x 730 | 2120 x 960 x 1020 | 4 | 780 x 635 | 300 | 375 |
NLDF34MI | 34 | 1050 | 1200 x 1200 x 730 | 2110 x 1360 x 1020 | 8 | 510 x 635 | 325 | 425 |
NLDF54MI | 54 | 1500 | 1200 x 1500 x 830 | 2110 x 1660 x 1120 | 8 | 660 x 735 | 350 | 450 |
Temperature Range | 20°C to 60°C |
Temperature Accuracy | ± 0.5°C |
Temperature Uniformity | ± 1°C |
Humidity Range | 40% RH to 95% RH |
Humidity Accuracy | ± 2% RH |
Humidity Uniformity | ± 3% RH |
Double walled with PUF insulation. | Stainless Steel trays |
SS 304 Interior & Exterior either SS 304 or Mild Steel | Full-length inner glass door & metal door with gasket & lock on the outside |
Internal LED lights | Forced air circulation for uniform temperature |
PU wheels for easy movement | U-shaped SS tubular heaters |
Non condensing steam injection type humidity system with standby heater & auto switch overs | CFC free cooling system consisting of hermetically sealed compressor coupled with evaporation coil & condenser |
Stand by humidity system with booster humidification | Complete Operations driven through PLC with data logging capacity of upto 1000 readings |
High speed Ethernet based communication | All operations through a single 7″ Color Touch Screen |
High quality imported make T/Rh combo sensor with 4-20 mA output | Safety devices: Low & high temperature cut-off settable thermostats |
Audio/Visual alarms for deviations | Complete with DQ, IQ, OQ, PQ & SOP & Maintenance Manual |
ICDAS – A Common Software suitable for 20 nos. Newtronic make equipments | Door Access system (Numeric or Biometric) |
4pt. Temperature & Humidity Scanner | Mobile Alert system |
Stand by Cooling System with auto switch overs (430 litre & above) | Remote alarm system suitable for 4 nos. Newtronic make equipments |
Model | Capacity – CuFt. | Capacity – Litres | Internal Size – (HxWxD) mm | External Size – (HxWxD) mm | Trays Qty. | Tray Size – (WxD) mm | Approx. Weight – Eqip. Kg | Approx. Weight – Ship. Kg |
---|---|---|---|---|---|---|---|---|
NLHC7SI | 7 | 200 | 800 x 500 x 500 | 1315 x 660 x 985 | 3 | 430 x 460 | 150 | 225 |
NLHC16SI | 16 | 430 | 1200 x 600 x 600 | 1715 x 760 x 1155 | 4 | 530 x 560 | 250 | 325 |
NLHC26SI | 26 | 735 | 1500 x 700 x 700 | 2070 x 860 x 1255 | 5 | 630 x 660 | 275 | 350 |
NLHC34SI | 34 | 1000 | 1500 x 800 x 800 | 2070 x 960 x 1355 | 5 | 730 x 760 | 350 | 425 |
NLHC54SI | 54 | 1500 | 1500 x 1600 x 600 | 2070 x 1760 x 1155 | 10 | 695 x 560 | 350 | 450 |
NLHC71SI | 71 | 2000 | 1500 x 1600 x 800 | 2070 x 1760 x 1355 | 10 | 695 x 760 | 375 | 475 |
