The designs facilitate two different temperature ranges in a single equipment. The Upper chamber is set at 4°C and the Lower chamber is set at -25°C.
To ensure smooth operations & energy efficiencies, the cooling operations are managed through a single compressor.
Offers high-speed data transfer, surpassing serial (RS-485) communication, and adheres to a global standard for communication protocol, enabling data operations from any PC over the LAN without requiring a separate PC interface.
Time of Alarm transmission, Name of Equipment, Transmitted message(Equipment name, alarm time, type of alarm & limits).
21 CFR Part 11 Ready, Single software suitable for upto 20 equipments, Automatic daily data back-up, Alarm logs. Alarm acknowledgement with e-signatures, Audit trails, MKT Calculations, Graphical viewing & data trending, Data export in pdf format.
Temperature & Humidity Deviations, Door Opening, Component Failure, Mains Failure.
IQ, OQ, PQ, Calibration certificates, Operations & maintenance manuals, GA & Electrical drawings, Material test certificates, Training to end-users.
Temperature Overshoot/Undershoot, Delay Timer to safeguard the Compressor, MCB to cut-off over-current supply, Standby Controlling Sensor upon failure of Primary.
| Upper Temperature Range | 2°C to 8°C |
| Lower Temperature Range | -10°C to -25°C |
| Upper Temperature Accuracy | ±0.5°C |
| Lower Temperature Accuracy | ±3°C |
| Upper Temperature Uniformity | ±1°C |
| Lower Temperature Uniformity | ±5°C |
| Double wall PUF insulation | Interior SS304 & Exterior PPGL |
| Stainless Steel Trays in the upper compartment & Baskets in the lower compartment | Doors with magnetic gasket for all airtight sealing |
| Forced air circulation for uniform temperature | PU Wheels for easy movement |
| CFC free cooling system consisting of hermetically sealed compressor coupled with evaporation coil & condenser (one for each compartment) | Complete operation are driven through IOT-enabled Controller with data logging capacity of upto 1000 readings |
| High speed Ethernet based communication | All operations through a single 7" Color Touch Screen Display |
| High-quality PT-100 Temperature sensor | Safety devices: Low Temperature cut-off, settable thermostats |
| Audio/Visual alarms for deviations | Complete with DQ, IQ, OQ, PQ, SOP & Operational Manual |
Power Supply: 230 volts 50 Hz main supply. Also available with 60 Hz Cycle.
| ICDAS -A Single Software installation for all Newtronic make equipments | Remote alarm system suitable for upto 4 nos. Newtronic make equipments |
| Mobile Alert System |
| Model | Capacity | Internal Size | External Size | Trays Qty. | |
|---|---|---|---|---|---|
| CuFt. | Liter | (H*W*D) mm | (H*W*D) mm | ||
| NLCR17MIC | Upper - 7 | Upper – 300 | Upper - 765 x 625 x 630 | 2050 x 785 x 945 | Upper – 3 |
| Lower – 7 | Lower – 165 | Lower - 440 x 625 x 600 | Lower – 2 | ||
